LT Voltage Transformer (Metering)
A precision dry-type unit for panel voltage metering and protection, built to class 0.2/0.5 accuracy for revenue and monitoring applications.
Know More
Low Voltage Voltage Transformer · Up to 1.1kV
Low Voltage Voltage & Control Transformers up to 1.1kV
Compact LT voltage and control transformers for panel metering, control circuits and instrumentation up to 1.1kV.
- Compact dry-type construction for panel-mount metering and control circuits
- Accuracy class 0.2/0.5 metering, standard control-transformer ratings also available
- Epoxy or varnish-impregnated windings — low maintenance, long service life
- Standard and custom ratios for switchgear, panel and control-circuit applications
Certifications
Certified and Approved For
IEC Compliant Designs
NABL Accredited Lab
ISO 14001:2015
ISO 9001:2015
Technical Specifications
Technical Specifications
Product TypeLow Tension (LT) Voltage / Control Transformer
Voltage RangeUp to 1.1kV
Applicable StandardsIEC 61869-3, IS 3156, IS 12021 (control transformers)
Rated Primary VoltageUp to 1100V
Rated Secondary Voltage110V, 63.5V, or as specified
Accuracy Classes0.2 | 0.5 | 1 (metering); standard duty (control)
Burden Ratings10 VA to 500 VA, or customer-specified
Insulation TypeDry-Type (Epoxy or Varnish Impregnated)
Frequency50Hz / 60Hz
InstallationIndoor Panel-Mount
Product Types
Types of Low Voltage Voltage & Control Transformers up to 1.1kV
LT Control Transformer
A robust step-down transformer supplying control, indication and auxiliary circuits within LT switchgear and panels — sized for duty rather than metering accuracy.
Know More
Key Features
Key Features of Our Low Voltage Voltage & Control Transformers up to 1.1kV
Voltage rating up to 1.1kV, suitable for all LT panel and switchgear applications
Metering accuracy class 0.2/0.5 where required for revenue metering
Standard control-transformer duty ratings for auxiliary and indication circuits
Designed and tested in compliance with IEC 61869-3 and IS 3156
Dry-type construction — no oil, low maintenance, compact footprint
Custom secondary voltage and burden configurations available
Tested in-house before dispatch
LT voltage and control transformers supply the metering, indication and control circuits inside LT panels and switchgear. Straton Electricals manufactures both precision metering-grade units and general-duty control transformers, sized to fit standard panel-builder layouts.
Applications
Applications of Low Voltage Voltage & Control Transformers up to 1.1kV
LT Switchgear & Distribution PanelsMotor Control Centres
Energy Metering Panels
Industrial Control PanelsBuilding Management Systems
Solar Inverter MeteringStraton Electricals LT voltage and control transformers are used throughout LT switchgear and control panels where dependable, compact voltage supply matters — for both revenue-grade metering and everyday control-circuit duty.
FAQ
Frequently Asked Questions
A voltage transformer is built for measurement accuracy (metering and protection), while a control transformer is built for duty — supplying control, indication and auxiliary circuits reliably rather than measuring voltage precisely.
Metering-grade LT voltage transformers are available in accuracy class 0.2, 0.5 or 1, depending on the application.
Yes — secondary voltage and burden are commonly matched to a specific panel or control-circuit requirement; contact our engineering team with your specification.
Dry-type construction, either epoxy or varnish-impregnated windings, avoiding the maintenance requirements of oil-filled units.
Dry-type construction means minimal routine maintenance under normal conditions. Periodic visual inspection and insulation resistance testing are still good practice as part of a panel's general maintenance schedule.
Talk To Us
Need Help Selecting the Right Low Voltage Transformer?
Straton Electricals offers customized low voltage transformer solutions for panel builders, OEMs, and industrial control systems. Contact our engineering team for technical support and product selection.
Downloads
Download Technical Specifications
Users can download detailed technical documents for product selection and engineering reference.
